Material: Anodized aluminium profile; screw and nut made of steel; polyamide handwheel; zinc plated steel screws
Function: For a rigid and precise accessories positioning on assembly or packaging lines along horizontal and vertical axes, or along two main axes
Screw pitch: 4 mm
Standard stroke: 300 mm for each axes
Tailored stroke: When ordering indicate 042004PC stroke axis1 + stroke axis2
Example: 042004PC 400+500
Assembly set: With handwheel; with linear recirculating balls guideway; analogical
Optional features: Clockwise (dx) or counterclockwise rotation (sx)
Position indicator: Direct drive, analog, black, four digits, numbers height 5 mm; when ordering indicate:
1) Positioner code
2) “ip” with direction of rotation (dx or sx)
Example: 042004P/ipdx or 042004P/ipsx
